If you’ve ever opened a geotechnical report and found an allowable bearing pressure without immediately knowing whether it is gross or net, you’re not alone.

This is one of those topics that regularly causes confusion, especially for younger engineers. The terminology sounds straightforward, but using the wrong interpretation can lead to an unconservative design—or an overly conservative one.

The good news is that the solution is usually much simpler than memorizing formulas.

Start by Understanding What the Report Means

The most important takeaway is that there is no universal convention.

Some geotechnical reports provide gross allowable bearing pressure, while others provide net allowable bearing pressure. In some regions one convention dominates, while in others the opposite is common. Because of this, assuming the meaning of a reported value based solely on local experience can be risky.

Before performing any calculations, read the report carefully and determine exactly how the allowable pressure has been defined. If the report is not explicit, ask the geotechnical engineer for clarification rather than making assumptions.

Gross vs. Net Bearing Pressure

The distinction comes down to what load is acting on the soil.

Gross bearing pressure represents the total stress acting at the foundation level. It includes not only the structural load but also the effects of footing self-weight and any overburden acting on the foundation.

Net bearing pressure represents the additional stress imposed by the new structure after accounting for the soil that originally occupied that location before excavation.

An intuitive way to think about it is this:

Imagine excavating a basement. Before construction, the soil at the founding level was already supporting the weight of the soil above it. Once that soil is removed, part of the structural load simply replaces the weight that previously existed rather than adding entirely new stress.

That difference is what net bearing pressure attempts to capture.

Why Basement Foundations Can Be Different

Consider a raft foundation constructed inside a basement excavation.

A significant amount of soil has been removed before the raft is built. The structural load transmitted through the raft is therefore partially offset by the weight of the excavated soil.

This is sometimes referred to as a compensated foundation or floating foundation, where the increase in stress within the soil may be considerably less than the total building load would suggest.

This explains why engineers often discuss net bearing pressure when dealing with basement rafts.

Spread Footings Require More Attention

For isolated or strip footings, the situation is often less straightforward.

If portions of the footing extend beyond the basement wall, those areas may later be covered with backfill. That backfill contributes additional loading that should not be ignored.

Likewise, footing self-weight may or may not already be accounted for depending on whether the reported allowable pressure is gross or net.

These details illustrate why simply selecting “gross” or “net” without understanding the assumptions behind the geotechnical report can easily produce incorrect bearing checks.

Run the Numbers: Net Allowable, Gross Check

The theory above is simple. The arithmetic is where most of the mistakes happen, so here is one check worked through end to end.

Take a 2.00×2.002.00 \times 2.00 m spread footing. The report gives a net allowable bearing pressure of 150 kPa (3,133 psf), and it does say the value is net.

InputSymbolSIImperial
Footing width × lengthB×LB \times L2.00 × 2.00 m6.56 × 6.56 ft
Embedment depthDfD_f1.50 m4.92 ft
Footing thicknesstt0.40 m1.31 ft
Column service loadPP550 kN123.6 kip
Unit weight of backfillγ\gamma18 kN/m³115 pcf
Unit weight of concreteγc\gamma_c24 kN/m³153 pcf
Net allowable bearing pressure (as reported)qa,netq_{a,net}150 kPa3,133 psf

1. Footing self-weight. Wf=2.00×2.00×0.40×24=38.4W_f = 2.00 \times 2.00 \times 0.40 \times 24 = 38.4 kN

2. Backfill over the footing. The excavation is 2.00×2.00×1.50=6.02.00 \times 2.00 \times 1.50 = 6.0 m³ and the footing takes up 1.6 m³ of it, so Vbf=4.4V_{bf} = 4.4 m³ and Wbf=4.4×18=79.2W_{bf} = 4.4 \times 18 = 79.2 kN.

3. Gross applied pressure. qg=(550+38.4+79.2)/4.00=166.9q_g = (550 + 38.4 + 79.2) / 4.00 = 166.9 kPa (3,486 psf)

4. Net applied pressure. qnet=166.9−18×1.50=139.9q_{net} = 166.9 - 18 \times 1.50 = 139.9 kPa (2,922 psf)

5. Allowable pressure on the gross basis. qa,gross=150+27=177.0q_{a,gross} = 150 + 27 = 177.0 kPa (3,697 psf)

P = 550 kNWbf = 79.2 kNWf = 38.4 kNt = 0.40 mDf = 1.50 mq net = 139.9 kPaγDf = 27.0 kPaq gross = 166.9 kPa2.00 m
The same footing on both bases: the gross pressure under the base is the net pressure plus the overburden γDf the soil carried before the excavation.

The surcharge at founding level, γDf=27\gamma D_f = 27 kPa, is all that separates the two bases, and it is 18 % of the 150 kPa net allowable: enough to change the outcome of the check.

Check performedValue vs. limitVerdict
Net against net allowable (correct)139.9 vs. 150 kPaPasses, 10.1 kPa (211 psf) margin
Gross against gross allowable (correct)166.9 vs. 177.0 kPaPasses, 10.1 kPa (211 psf) margin
Gross against net allowable (mixed)166.9 vs. 150 kPaFails: a false alarm, 16.9 kPa (353 psf) over
Net against gross allowable (mixed)139.9 vs. 177.0 kPaPasses with 37.1 kPa (775 psf), a margin that does not exist

The two correct checks give the same margin, because the difference between gross and net is the same overburden on both sides. Mixing the bases adds 27 kPa to the margin or takes it away.

What the reference manual says

The FHWA Soils and Foundations reference manual (FHWA NHI-06-089, Volume II, §8.4.7) makes the same point from the other side. Structural designers normally already include the footing self-weight and the backfill above it — roughly γaDf\gamma_a D_f — in the loads they hand over. So when the geotechnical engineer reports a net allowable pressure derived from a net ultimate value, the surcharge over the footing gets counted twice:

The structural designer will typically include the self-weight of the concrete footing and the backfill over the footing (approximately equal to γaDf) in the loads that contribute to the applied bearing stress. Therefore, if the geotechnical engineer computes and reports a net ultimate bearing pressure, the effect of the surcharge directly over the footing area is counted twice.

The manual’s guidance follows: an allowable computed from a net ultimate pressure is conservative and generally not recommended, and if it is reported that way the report must state it clearly. The same section also asks that the footing width used in the analysis always be included, because the capacity was computed for one specific width.

That gives the practical rule: never take the number out of the report without taking its basis and its footing width with it. If either is missing, ask — a five-minute question costs nothing next to a foundation checked against the wrong limit.

Two ways the check still goes wrong

  • Water table above the base. The surcharge is γDf\gamma D_f only while the soil above the base is dry. If the water table sits above founding level, the correct figure is effective stress — total unit weight down to the water table and buoyant unit weight below it — and using γDf\gamma D_f throughout overstates the surcharge.
  • Settlement does not run on the gross pressure. Settlement is driven by the net increase in stress, so it is checked against the net pressure whatever basis the bearing report uses. A footing that passes the bearing check can still be governed by settlement; the calculation is in how foundation settlement is calculated, and the report-reading side is covered in how to read a geotechnical report.

Settlement May Control Before Bearing Capacity

Another important point is that satisfying the allowable bearing pressure does not necessarily mean the foundation is adequately designed.

For many raft foundations, settlement, particularly differential settlement, becomes the governing design criterion well before bearing capacity is reached.

Bearing capacity is only one piece of the foundation design process. Settlement, serviceability, and structural behavior must all be evaluated together.

Practical Recommendations

When reviewing a geotechnical report:

  • Verify whether the allowable bearing pressure is defined as gross or net.
  • Read the accompanying notes instead of relying only on the summary table.
  • Consider whether excavation has removed significant overburden.
  • Account for footing self-weight and backfill consistently with the reported definition.
  • When in doubt, contact the geotechnical engineer who prepared the report.

A five-minute conversation is often far more valuable than trying to infer the intended meaning from a single number.

To see where an ultimate and an allowable bearing capacity come from, the free bearing capacity calculator works out a footing on Rischio’s engine with the general equation, and gives Terzaghi’s on the same page to compare.

Final Thoughts

The distinction between gross and net bearing pressure is less about memorizing definitions and more about understanding what stresses the soil is actually experiencing.

Different firms, regions, and software packages may adopt different conventions, but one principle remains constant: always use the allowable bearing pressure exactly as it was defined in the geotechnical report.

A foundation design is only as reliable as the assumptions behind the numbers.
